EXODUS - Pulse High Power Amplifier Modules

Exodus Advanced Communications Pulse HPA BUC (Block Up Converter) Header

Exodus Advanced Communications Pulse High Power Block Up Converter (BUC) from 1MHz to 12GHz

Exodus Pulse SSPA (Solid State Power Amplifiers) products feature LDMOS, GaN discrete, and Chip & Wire technologies covering frequency ranges from 1MHz to 12GHz at power levels exceeding 1KW for Modules and 10KW for Systems.

Exodus Advanced Communications is a multinational RF communication equipment and engineering service company serving both commercial and government entities and their affiliates worldwide.

Our In-house resources include RF circuit designs up to 51GHz, prototype verification, system level mechanical & electrical design, digital circuit design, and control software development.  We bring over 100 years of combined experience in the RF field designing RF SSPA's in numerous applications including military jamming, communications, radar, EMI/EMC and various commercial projects.  Our technologies and capabilities include:

  • High Power Solid-State Power Amplifiers
    • Chip & Wire Hybrid Assemblies, Modules & Systems
    • Broadband, CW, Pulse & Linear Applications
    • 1MHz to 50GHz, 3KW CW, 10KW Pulse
  • Medium Power Amplifiers
    • 1MHz to 51GHz, up to 2W P1dB
  • Low Noise Amplifiers
  • Block Up Converters
  • Antennas - 2MHz to 40GHz.
  • Packaging, Heat Control, Environmental qualification.
  • High Level Firmware integration for system level applications & Web browser, Bluetooth/internet enabled for easy user interface via PC, smartphones, or tablets.

MODULE
MODELS

MIN
FREQUENCY

(MHz)

MAX
FREQUENCY

(MHz)

 OUTPUT
(W or dBm)

GAIN
(dB)

SOURCE
(Volt)

DATA
SHEETS

AMP1109P

1

20

400

40

24

pdf

AMP1155P

100

500

500

57

28-30

pdf

AMP3114P

140

180

2500

64

50

pdf

AMP3117P

150

250

1500

62

50

pdf

AMP1156P

150

500

4000

60

50

pdf

AMP1155P-1

170

500

500

57

28-30

pdf

AMP1148P

400

1000

2000

60

50

pdf

AMP5057P

595

605

1000

60

50

pdf

AMP5035P-4

915

915

4000

66

50

pdf

AMP3020P

950

1250

4000

65

50

pdf

AMP3121P

950

1250

1200

16

48

pdf

AMP3061P

950

1250

2000

64

50

pdf

AMP3119P

960

1220

135

51

32

pdf

AMP5016P

1000

1000

4000

63

46

pdf

AMP5018P

1000

1000

2000

63

46

pdf

AMP1145AP

1000

2000

1100

61

50

pdf

AMP3018P

1020

1040

60

58

28

pdf

AMP3047P

1025

1150

2000

63

50

pdf

AMP3020-1P

1030

1030

2000

20-30

50

pdf

AMP5009P

1030

1090

2000

63

46

pdf

AMP5011P

1030

1030

600

58

46

pdf

AMP5015P

1030

1030

200

20

28

pdf

AMP5030P

1030

1030

65

15+28

28-30

pdf

AMP5009ZP

1030

1090

2000

15

46

pdf

AMP3032P

1200

1400

500

57

40-42

pdf

AMP3091P

1200

1400

1000

60

50

pdf

AMP1100P

2000

4000

200

53

28

pdf

AMP5026P

2050

2250

700

20

28

pdf

AMP3031P

2700

2900

1300

50

50

pdf

AMP3030P

2700

3300

50

50

32

pdf


MODULE
MODELS

 MIN
FREQUENCY
(MHz)

 MAX
 FREQUENCY
(MHz)

OUTPUT
(W or dBm)

GAIN
(dB)

SOURCE
(Volt)

DATA
SHEETS

AMP3110P

2700

3100

1000

60-64

50

pdf

AMP3090AP

2700

3100

500

57

50

pdf

AMP5052P

2700

2900

65

48

28-30

pdf

AMP5005P

2856

2856

450

56

48

pdf

AMP3090P-2

2900

3100

200

54

50

pdf

AMP3090P-1

2900

3100

400

56

50

pdf

AMP5021P

3000

3000

300

55

45

pdf

AMP5023P

3000

3000

400

56

50

pdf

AMP3090BP

3100

3400

300

55

32

pdf

AMP5062P

3600

3600

1300

62

50

pdf

AMP5061P

3900

3900

1000

60

50

pdf

AMP3041P

4400

5000

100

65

28

pdf

AMP3113BP

5000

5500

100

50

30-32

pdf

AMP3113P

5200

5500

100

65

30-32

pdf

AMP3096P-1

5350

5460

400

30

50

pdf

AMP3096P

5400

5900

300

55

50

pdf

AMP3096AP

5400

5900

1100

40

50

pdf

AMP5044P

5410

5410

200

30

28

pdf

AMP5051P-TDWR

5600

5650

20

50

28

pdf

AMP5006P

5712

5712

500

57

24

pdf

AMP3112A-1P

7500

10000

50

47

40

pdf

AMP3112P-2

7500

10000

500

57

32

pdf

AMP3112AP

7500

10000

300

55

40

pdf

AMP3085P

8000

12000

100

50

32

pdf

AMP3010AP

8500

10200

100

50

40

pdf

AMP5039P

9100

9900

1000

60

42

pdf

AMP3009P-2

9100

9500

200

53

49

pdf

AMP3004-1P

9100

9500

200

48

30

pdf

AMP3076P

9300

9500

2000

20

48

pdf

AMP3019P

9350

9750

300

54

31-33

pdf

AMP3080P

9500

10000

300

55

30

pdf

AMP3112P

9500

10000

300

55

32

pdf

AMP3076P-1

9500

9700

2000

53

48

pdf

AMP5047P

9700

9900

1000

60

42

pdf

AMP3008P

9750

10250

50

47

27-29

pdf

AMP5059P

11900

12100

400

56

42

pdf

AMP3126P

12000

18000

100

50

40

pdf

AMP5048P

16300

16700

160

52

40

pdf


High Power Amplifier Module Options

Installed at Time of Order

Ethernet RJ-45 TCP/IP, RS422/485, USB, Optional GPIB Interface, Bluetooth Application

Digital Monitor & Control FWD, REV, VSWR, GAIN, ALC, V & I, TEMP

Front or Rear Panel Connectors

Auto Shutdown with Controller
